MDPs and the Bellman Equation: The Recursion Behind Every RL Algorithm

The throughline: The value of where I am is the reward I just got, plus a discounted value of where I’ll land next.

The RL Foundations post gave us the vocabulary (policy, reward, value) and the math toolkit (expectation, discounting, the Markov property). This post puts those pieces together into a precise machine: the Markov Decision Process (MDP) formalizes the environment, value functions score how good a state or action is, and the Bellman equation expresses value as a recursion, one equation that every RL algorithm is, at its core, a way of solving.

1. The intuition: one loop, one lookup table, one recursion

The agent–environment loop, one more time

Every RL problem is the same loop. At each discrete time step $t$:

flowchart LR
  agent["Agent (policy π)"]
  env["Environment (dynamics p)"]
  agent -->|"action Aₜ"| env
  env -->|"reward Rₜ₊₁, next state Sₜ₊₁"| agent

The agent observes state $S_t$, picks action $A_t$ according to its policy $\pi$, the environment responds with reward $R_{t+1}$ and next state $S_{t+1}$, and the cycle repeats. The full history is a trajectory:

What makes an environment an MDP?

An MDP is a tuple $(\mathcal{S}, \mathcal{A}, p, R, \gamma)$:

• $\mathcal{S}$: a finite set of states (every cell on a grid, every board position in chess).
• $\mathcal{A}$: a finite set of actions (left/down/right/up on a grid).
• $p(s', r \mid s, a)$, the dynamics function: the probability that action $a$ in state $s$ leads to next state $s'$ with reward $r$. This single function is the complete DNA of the environment. If you have it, you can plan (dynamic programming). If you don’t, you must learn from experience (Monte Carlo, TD).
• $R$: the set of possible reward values.
• $\gamma \in [0, 1)$: the discount factor (introduced in RL Foundations, §2.5).

“Finite” just means you can count the states, actions, and rewards: you could list them all on a whiteboard. FrozenLake has 16 states, 4 actions, and rewards in $\{0, 1\}$.

The Markov property (quick recap)

The dynamics depend only on $(S_t, A_t)$, not on how you got there. This isn’t magic: it’s a constraint on what counts as the state. If history matters, pack it into the state (frame-stacking in Atari, full transcript in a chatbot). The payoff: value can be a function of $s$ alone.

The agent–environment boundary

A subtle point: the boundary is control, not anatomy. A robot’s motors and gears are part of the environment: the agent sends voltage commands, but what the motors do follows physics, not the agent’s wishes. Even if the agent knows the rules perfectly (like in chess), the reward computation is still “outside”; it defines the task, it doesn’t solve it.

The reward hypothesis

All goals can be thought of as the maximization of the expected cumulative sum of a scalar reward signal.

Bold claim, but it works: chess ($+1$ win, $-1$ loss), maze ($-1$ per step, so hurry!), walking robot (reward proportional to forward speed). The critical design principle: reward says what to achieve, not how. If you reward a chess agent for capturing pieces, it might sacrifice a winning position to grab a queen.

2. The math you need

2.1 The dynamics function $p(s', r \mid s, a)$

This is a lookup table: plug in four things (current state $s$, action $a$, next state $s'$, reward $r$) and get back a probability. For any fixed $(s, a)$, the probabilities over all $(s', r)$ outcomes sum to 1:

In Gymnasium, this table lives in env.unwrapped.P. Each entry is a list of (probability, next_state, reward, done) tuples, exactly $p(s', r \mid s, a)$:

import gymnasium as gym

# Create the 4x4 FrozenLake with slippery ice (stochastic transitions).
# is_slippery=True means each action has only 1/3 chance of going where intended;
# the other 2/3 of the time the agent slides perpendicular.
env = gym.make("FrozenLake-v1", is_slippery=True)

# P is the full dynamics table p(s', r | s, a).
# P[s][a] returns a list of (probability, next_state, reward, done) tuples
# for every possible outcome of taking action a in state s.
P = env.unwrapped.P

# Query: "What happens if I try to go Right (action=2) from state 6?"
# state 6 (row 1, col 2), action Right
state, action = 6, 2
print(f"p(s', r | s={state}, a={action}):")
for prob, next_state, reward, done in P[state][action]:
    # Each tuple is one branch of the stochastic outcome:
    # prob = p(s',r|s,a), the transition probability for this specific outcome
    print(f"  prob={prob:.4f}  s'={next_state:2d}  r={reward:.0f}  done={done}")
env.close()

p(s', r | s=6, a=2):
  prob=0.3333  s'=10  r=0  done=False
  prob=0.3333  s'= 7  r=0  done=True
  prob=0.3333  s'= 2  r=0  done=False

Because the ice is slippery, action “Right” from state 6 has only a 1/3 chance of actually going right (to state 7, a hole!). The other 2/3 of the time the agent slides down or up. This is the stochasticity that makes the problem an MDP rather than a deterministic puzzle.

2.2 Returns: what exactly are we maximizing?

The agent doesn’t maximize a single reward; it maximizes the return $G_t$, the cumulative discounted reward from time $t$ onward:

• Episodic tasks (chess, maze) end at some terminal step $T$; the sum is finite even without discounting.
• Continuing tasks (thermostat, stock trader) run forever; discounting with $\gamma < 1$ keeps the sum finite: $G_t \le \frac{R_{\max}}{1 - \gamma}$.

The discount factor $\gamma$ answers “how far-sighted is this agent?” ($\gamma = 0$: myopic; $\gamma \to 1$: values the distant future almost equally).

A quick calculation: with $\gamma = 0.99$ and $R_{\max} = 1$, the return is bounded by $\frac{1}{1 - 0.99} = 100$. That finite ceiling is why the Bellman equation works for infinite-horizon tasks.

2.3 The recursive return: the heartbeat of RL

The most important algebraic trick in all of reinforcement learning. Start with the definition of $G_t$ and factor out $\gamma$:

The return from now equals the immediate reward plus $\gamma$ times the return from one step later. This one-step recursion is what makes the Bellman equation work: the whole chain of future rewards collapses into a single recursive step.

2.4 Value functions: $V$ vs $Q$, the emphasis

Two ways to score “how good”:

State-value function $V^\pi(s)$, one number per state:

Read: “V-pi of s equals the expected return G_t, given that the current state is s, when following policy pi.”

Interpretation: if I start in state $s$ and follow policy $\pi$ from here on, what return should I expect on average?

Action-value function $Q^\pi(s, a)$, one number per state-action pair:

Read: “Q-pi of s, a equals the expected return G_t, given that the current state is s and the action taken is a, when following policy pi afterward.”

Interpretation: if I start in state $s$, take action $a$, then follow $\pi$ afterward, what return should I expect?

$Q$ breaks $V$ open per action. $V$ tells you how good a state is; $Q$ tells you which action makes it that good. Both depend on the policy: same state, different policy, different value.

The V-Q bridge (both directions)

$V$ and $Q$ are two views of the same thing, connected by two equations:

Read: “V-pi of s equals the sum over all actions a of the policy probability pi(a|s) times Q-pi(s, a).”

Interpretation: $V$ is the policy-weighted average of $Q$. You average the action-values over the actions the policy would take: if the policy spreads 70% on left and 30% on right, V is 0.7·Q(left) + 0.3·Q(right).

Read: “Q-pi of s, a equals the sum over all possible next states s’ and rewards r of the transition probability p(s’,r|s,a) times [r + gamma times V-pi(s’)].”

Interpretation: $Q$ is the environment-weighted average of $[r + \gamma V']$. You average over where the environment sends you: each landing spot contributes its immediate reward plus the discounted value of landing there, weighted by how likely that transition is.

The two diagrams below visualize these equations as a tree and a bar chart.

Reading the backup diagram (tree). Start at the top: the single $V$ node is the state you’re in. Going down one level, it branches into multiple $Q$ nodes, one per action the policy might take. The edges are labeled $\pi(a_i)$: the probability the policy gives to each action. This is the first equation ($V = \sum_a \pi \cdot Q$): V averages over actions using policy probabilities. Going down another level, each $Q$ node branches into multiple $V'$ nodes (next states). The edges are labeled $p(s', r \mid s, a)$: the transition probabilities from the environment. This is the second equation ($Q = \sum_{s'} p \cdot [r + \gamma V']$): Q averages over next states using environment probabilities. Together, the full tree from top to bottom is the expanded Bellman equation: two layers of averaging (agent choice, then environment randomness).

Reading the bar chart. Each bar is $Q^\pi(s, a)$ for one action (Left, Down, Right, Up) at a single state. The bars have different heights because some actions lead to better outcomes than others (Right is tallest here: it leads toward the goal). The dashed horizontal line is $V^\pi(s) \approx 0.026$: the policy-weighted average of all four Q-values. Under a uniform policy ($\pi = 0.25$ for each action), that average is simply $(Q_\text{Left} + Q_\text{Down} + Q_\text{Right} + Q_\text{Up}) / 4$, which lands between the bars, not at any single bar’s height. This is the V-Q bridge in a picture: V is just the expected Q under the policy.

Why $Q$ matters more in practice

With $V(s)$ alone, choosing an action requires the model: “if I take action $a$, where do I land, and what’s $V(s')$ there?” That needs $p(s' \mid s, a)$.

With $Q(s, a)$, choosing is trivial: pick $\arg\max_a Q(s, a)$. No model needed. This is why DQN learns $Q$, not $V$, and the policy falls out of the argmax for free:

Read: “Pi-star of s equals the action a that maximizes Q-star(s, a).”

Interpretation: the optimal policy just picks whichever action has the highest Q-value. No search, no model, just compare numbers and take the biggest.

Here’s the bridge in code. The key question: how does each equation become a loop?

Equation → code for $Q$ from $V$:

The sum says: “loop over every possible outcome $(s', r)$ of taking action $a$ in state $s$.” Each outcome has a probability $p$ and contributes $p \times [r + \gamma \cdot V(s')]$ to the total. In Gymnasium, P[s][a] gives exactly that list of outcomes as (prob, next_state, reward, done) tuples, so the sum becomes a for-loop accumulating prob * (reward + gamma * V[next_state]).

Equation → code for $V$ from $Q$:

The sum says: “loop over every action $a$.” Each action has a policy probability $\pi(a|s)$ and contributes $\pi(a|s) \times Q(s, a)$. Under a uniform policy, every action gets weight $0.25$, so V is just the average of the four Q-values.

import gymnasium as gym
import numpy as np

env = gym.make("FrozenLake-v1", is_slippery=True)
P = env.unwrapped.P
nS, nA = 16, 4
gamma = 0.99

# Start with a rough placeholder V(s) to demonstrate the V↔Q bridge.
# In practice, V would come from solving the Bellman equation; here we
# seed it with small random values and set known terminal states.
V = np.random.default_rng(0).uniform(0, 0.1, size=nS)  # placeholder V
V[15] = 1.0  # goal state has high value (reward +1 for arriving)
V[[5, 7, 11, 12]] = 0.0  # holes are absorbing with zero value


def q_from_v(V: np.ndarray, s: int, a: int) -> float:
    """Q^π(s,a) = Σ_{s'} p(s',r|s,a) · [r + γ·V(s')]

    Given I take action a in state s, what's my expected return?
    Averages over environment randomness (where do I land?).
    """
    q_value: float = 0.0
    # P[s][a] is the dynamics table: each entry is one possible outcome
    # of taking action a in state s.
    for prob, next_state, reward, done in P[s][a]:
        # This one line IS the equation:
        # p(s',r|s,a)  ·  [r         + γ     · V(s')        ]
        q_value += prob * (reward + gamma * V[next_state])
    return q_value


def v_from_q(Q_values: list[float], pi_probs: list[float]) -> float:
    """V^π(s) = Σ_a π(a|s) · Q(s,a)

    What's the value of state s under policy π?
    Averages over agent randomness (which action do I pick?).
    """
    v_value: float = 0.0
    # Loop over every action: weight each Q-value by the policy probability
    for pi_a, q_a in zip(pi_probs, Q_values):
        # π(a|s) · Q(s,a)
        v_value += pi_a * q_a
    return v_value


# Compute Q(6, a) for all 4 actions, then recover V(6) from Q.
s = 6
Q_s = [q_from_v(V, s, a) for a in range(nA)]
pi_uniform = [0.25] * nA  # uniform random policy: equal weight on all actions

print(f"Q({s}, a) = {[f'{q:.4f}' for q in Q_s]}")
print(f"V({s}) via Q = {v_from_q(Q_s, pi_uniform):.4f}")
# Greedy action = argmax_a Q(s,a): the model-free decision rule.
# With Q in hand, acting optimally is just picking the largest number.
print(f"Greedy action = {np.argmax(Q_s)} ({['Left','Down','Right','Up'][np.argmax(Q_s)]})")
env.close()

Q(6, a) = ['0.0283', '0.0269', '0.0283', '0.0014']
V(6) via Q = 0.0212
Greedy action = 0 (Left)

$Q(6, \text{Left})$ is highest (tied with Right), so the greedy policy says “go Left” from state 6: no model needed at decision time, just compare four numbers.

2.5 The Bellman expectation equation

Now the payoff. Start from the recursive return $G_t = R_{t+1} + \gamma\,G_{t+1}$ and take the expectation conditioned on $S_t = s$:

Read: “V-pi of s equals the expected value of [R_{t+1} plus gamma times V-pi of the next state S_{t+1}], given S_t = s, under policy pi.”

Interpretation: the value of a state is the expected immediate reward plus the discounted value of the next state. This is the Bellman equation in one line. But that $\mathbb{E}_\pi[\cdots]$ still hides two sources of randomness: (1) which action the agent picks, and (2) where the environment sends it. Let’s peel them off one at a time.

Step 1: expand the expectation over the agent’s action randomness (policy $\pi$).

The expectation $\mathbb{E}_\pi[\cdots \mid S_t = s]$ is an average over everything random that can happen from state $s$. The first random thing is: which action does the agent pick? The probability of picking action $a$ is $\pi(a \mid s)$. By the law of total expectation (“split an average into cases and weight each case by its probability”):

So the full line becomes:

Why is there still an $\mathbb{E}$ inside? Because even after fixing the action, there is still randomness left: the environment hasn’t rolled its dice yet. We know the state ($s$) and the action ($a$), but the next state $S_{t+1}$ is still random (the ice is slippery!). The inner expectation averages over that remaining environment randomness.

Step 2: expand the remaining expectation over the environment’s state randomness (dynamics $p$).

Now we’re inside a fixed $(s, a)$ pair. The only randomness left is which next state $s'$ the environment produces, with probability $p(s' \mid s, a)$. Apply the same rule again (“split into cases, weight by probability”), but this time the cases are next states:

No $\mathbb{E}$ remains because once we fix $s$, $a$, and $s'$, nothing is random anymore: the reward $R(s,a,s')$ is a known number, and $V^\pi(s')$ is a fixed value for that next state.

Substituting Step 2 into Step 1 gives the full Bellman expectation equation:

Read: “V-pi of s equals the sum over actions a of pi(a|s) times the sum over next states s’ of p(s’|s,a) times [R(s,a,s’) + gamma times V-pi(s’)].”

Interpretation: for each action I might take (weighted by my policy), for each state I might land in (weighted by transition probability), add the reward I get plus the discounted value of where I land. Two nested sums, one per source of randomness, and once both are expanded there is nothing random left.

Both steps use the same rule: $\mathbb{E}[X] = \sum (\text{possible value}) \times (\text{probability})$. Step 1 applies it to actions (probabilities from $\pi$). Step 2 applies it to next states (probabilities from $p$).

This is one equation per state, and they all refer to each other: $V(s)$ depends on $V(s')$, which depends on $V(s'')$, and so on. That system of equations is what we solve in the capstone.

import gymnasium as gym
import numpy as np

env = gym.make("FrozenLake-v1", is_slippery=True)
P = env.unwrapped.P
nS, nA = 16, 4
gamma = 0.99

def bellman_backup(V: np.ndarray, s: int, pi: list[float]) -> float:
    """One Bellman expectation backup for state s:
    V^π(s) = Σ_a π(a|s) · Σ_{s'} p(s'|s,a) · [r + γ·V(s')]

    This computes a NEW estimate for V(s) by looking one step ahead:
    for each action (weighted by policy), for each next state (weighted
    by dynamics), accumulate [immediate reward + discounted future value].
    """
    total: float = 0.0
    for a in range(nA):
        for prob, s2, r, done in P[s][a]:
            # π(a|s) · p(s'|s,a) · [r + γ·V(s')]
            # Agent randomness × environment randomness × one-step lookahead
            total += pi[a] * prob * (r + gamma * V[s2])
    return total

# Initialize V to all zeros except the goal. This simulates "before any
# value has propagated": only the goal knows it's valuable.
V_test = np.zeros(nS)
# goal state has value 1 (reward = 1 for reaching it)
V_test[15] = 1.0
# uniform random policy
pi = [0.25] * nA

# One backup at state 6: can the goal's value reach state 6 in a single step?
# State 6 is several cells away from state 15, so the answer is no (0.0).
# Repeated backups (or solving the full system) propagate value outward.
v6 = bellman_backup(V_test, 6, pi)
print(f"Bellman backup at state 6: V(6) = {v6:.6f}")
env.close()

Bellman backup at state 6: V(6) = 0.000000

With all states at zero except the goal, the backup at state 6 gives zero because state 6 is too far from the goal for a single backup to propagate the value. Repeated backups (or solving the full system) are needed: that’s what the capstone does.

2.6 The Bellman optimality equation

Replace the policy’s weighted average $\sum_a \pi(a \mid s)\,(\cdots)$ with a maximum $\max_a\,(\cdots)$, and you get the equation for the optimal value:

Read: “V-star of s equals the max over actions a of the sum over next states s’ of p(s’|s,a) times [R(s,a,s’) + gamma times V-star(s’)].”

Interpretation: instead of averaging over actions according to some policy, pick the best action. The optimal value of a state is the value you get when you always choose the action that leads to the highest expected return.

The optimal action-value has its own recursion:

Read: “Q-star of s, a equals the sum over next states s’ of p(s’|s,a) times [R(s,a,s’) + gamma times the max over next actions a’ of Q-star(s’, a’)].”

Interpretation: the optimal value of taking action $a$ in state $s$ is the expected reward plus the discounted value of the next state, assuming you act optimally from that next state onward (that’s where the inner $\max_{a'}$ comes from).

Now notice what $Q^*$ gives you: a number for every action in every state, and that number already accounts for optimal behavior in the entire future. So if you had $Q^*$ in hand, choosing the best action would require zero planning: just compare the numbers and pick the largest. The optimal policy falls out for free:

Read: “Pi-star of s equals the action a that maximizes Q-star(s, a).”

Interpretation: once you have the optimal Q-values, the optimal policy is trivial: just pick the action with the highest Q. Every RL algorithm is, at its core, a way of computing or approximating these optimal values.

One more relation connects $V^*$ and $Q^*$ directly (compare this to the V-Q bridge from §2.4, which used a policy-weighted average; here the average becomes a max):

Read: “V-star of s equals the max over actions a of Q-star(s, a).”

Interpretation: the optimal value of a state is simply the Q-value of the best action available there. Under the optimal policy you always take the best action, so V and the best Q coincide.

Where did $\pi(a|s)$ go? Recall the general V-Q bridge: $V^\pi(s) = \sum_a \pi(a|s)\,Q^\pi(s,a)$ — a weighted average. For the optimal policy, the weighting is degenerate: $\pi^*(a|s) = 1$ for the best action and $0$ for all others. When you substitute that one-hot distribution into the sum, every term vanishes except the maximum. A weighted average with a one-hot weight vector is “pick the max.”

Worked example: the optimal policy on slippery FrozenLake

The heatmap above shows $V^*$ for every state (computed by value iteration, which we’ll derive in the next post). The arrows show $\pi^* = \arg\max_a Q^*$: the greedy policy that falls out of the optimal Q-values.

Why do the arrows look wrong? Many arrows point away from the goal: Left and Up in the top rows, Down at state 14 (the cell right next to the goal). This is correct and it’s entirely because the ice is slippery. On slippery FrozenLake, every action has only a 1/3 chance of going where intended; the other 2/3 of the time the agent slides perpendicular. So the optimal strategy isn’t “aim for the goal”, it’s “aim so that your slips land somewhere safe.”

Consider state 14 (value 0.86, one cell left of the goal). Right seems obvious, but:

• Right: 1/3 reaches the goal, but 1/3 slides up to state 10 (V = 0.62, far away). Q = 0.82.
• Down: 1/3 reaches the goal as a perpendicular slip, 1/3 stays at state 14 (V = 0.86), and 1/3 slips to state 13 (V = 0.74). All slip destinations are high-value. Q = 0.86.

Down wins because its worst-case slip is much better. The same logic explains the top-row arrows: by pointing Left or Up into the walls, the agent uses them as bumpers, since it can’t slip off the grid, so two of its three outcomes keep it in the same (safe) cell instead of sliding toward a hole. The optimal policy minimizes the damage from slips, not the distance to the goal.

2.7 The same recursion on a different surface

A remarkable claim: DQN, AlphaGo, PPO, and GRPO are all the same recursion, $V(s) = r + \gamma \cdot V(s')$, applied to different definitions of state, action, and reward:

The Bellman equation is the universal backbone. Everything else is engineering to make it work at scale.

3. Putting it all together

We’ve seen each idea in isolation. Here’s the whole vocabulary as a quick reference.

Where this goes next

We’ve formalized the environment as an MDP, defined $V$ and $Q$, and derived the Bellman equation. But writing the equation is not the same as solving it: finding the actual values requires either exact linear algebra (feasible only for tiny state spaces) or iterative/sampling methods. The next post introduces three classical approaches:

• Dynamic Programming: iterate the Bellman backup with the model (no sampling needed).
• Monte Carlo: sample full episodes and average the returns (no model needed).
• Temporal Difference: blend the two, updating after every step using a bootstrapped estimate.

All three converge to the same $V^\pi$, but they trade off bias (how far from the true value), variance (how noisy the estimates are), and data efficiency (how many samples are needed to converge). We’ll build a custom Mars Rover environment and watch all three converge on it from scratch.
